According to webopedia“Normalization is the formal process of determining which attributes should be grouped together in a relation”  What it means is that you are trying to group attributes that are related and that are key attributes.  You should try to get rid of non-key attributes and also make sure that relations make sense.  Normalization is used to be used as a tool to assist in grouping attributes in a relation.  We do normalization to have domain constraints, which is to make sure that the are no illegal values.  Also to ensure entity integrity which checks to make sure 3 things:



1)Every table/relation has only one primary key/unique identifier

2)We to make sure that the primary key is a unique identifier.

3)Last we must make sure there is a value for the primary key and that it is not null.



Now you ask how do I do this?



We need to establish a couple of general rules first.



Relational integrity



§         Relational rows must be consistent.



§         A foreign key cannot exist unless it is a primary key in another table and/relation.  The foreign key can also be null.















Here the situation:

A patient can only have one physician.  A physician can have many patients.

ONE to MANY relationship



The first major problem that we need to get rid of is repeating columns.  Repeating columns happen cause there many repeating values that are the same in many columns.





















Example:

PhysID	Name	PatID	PatID2	PatID3	PatID n
5	Paco	123456	234567	345678
6	Dave	666666
17	Larry	999999	444444





§         This is a one to many relationship but the problem is that we are putting PatID as the foreign key in the physician table, which is causing the multiple groups because as we said a physician can have multiple patients. As you saw in the example you see that a Physician has many patients and they can come multiple times for the same reason, which creates many problems and repeating groups.



We need to put it in (1NF)

Example:

PhysID	Name	PatID
5	Paco	123456
5	Dave	234567
5	Larry	345678
6	Joe	456789



§         Because there was a one to many relationship which caused the multiple groups we need to adjust our table.  We need to make sure that we have the PhysID in the patient table to eliminate the repeating groups.  Now we see a patient can only one physician and one physician can have many patients.



IMPORTANT TIPS:



1        All attributes of the Primary Key must be defined.

2        Must eliminate repeating groups.

3        Attributes must be functionally dependent on the primary key



Now we must look at FUNCTIONAL DEPENDENCY





When attributes can be determined by another attribute it means they are functionally dependent.  In the example you see that the attributes are not no longer functionally dependent on PhysID but on PatID as well.  This problem creates duplication and possibly errors.





Now we look at:  (2NF)

















We must assume certain things.



• We assume it is in 1NF
• One attribute as the primary key.
• Non-key attributes cannot exist
• Must have functional dependency of non-key attributes to the primary key.



Example:

PhysID	PhysName	PhysAddr	PatID	PatName	PatAddr	Front Desk
						Personnel
5	Paco	1615 Oregon	123456	David	999 Street	Betty



• As we see we do not have all non-key attributes functionally dependent on the primary key.  Front Desk personnel is not fully dependent on the primary key.



Example:

PhysID	PhysName	PhysAddr	PatID	PatName	PatAddr
5	Paco	1615 Oregon	123456	David	999 Street



• We see functional dependency is not happening here.  Certain non-key attributes refer to either PhsyID or PatID but remember they are composite keys.  You cannot use or.  They non-key must be dependent on both not one or the other.  PatID does not depend on the PhysID and PhysName does not depend  on PatID.  So if they are a composite that means all non-key attributes are dependent on the primary key which is the composite key of PhysID and PatID.





WHAT DO WE DO?????????



Can we get rid of those non-key attributes?  Maybe, if we put PhysID into our patient table as a foreign key then yes we can eliminate all non-key attributes.





SO WE DID IT





Physician Table

PhysID

PhysName

PhysAddr





Patient Table

PatID

PatName

PatAddr

PhysID



As you can see we put PhysID in the physician table which allows to not have to have two primary keys.  Remember we had to have PatID and PhysID as composite keys.  Now you can get all the Physician information from the physician table.











PhysID	PatID	PatName	PatAddr
5	123456	David	999 Street





• One attribute is used for the primary key  PhysID in Physician Table and PatID in Patient Table. We eliminated the non-key attributes that are not fully functionally dependent on the primary key.





MORE OH NO!!!!!!!!!!!!!













(3NF)

We must assume:



If we assume we have put it in 2NF then all that is left is to eliminate transitive relationships.



“Transitive Relationship is a functional dependency between two (or more) non-key attributes.”

Kirs –Lecture Slides



If we have a situation where we need to know a patient in order to find out a physician’s specialty then we have a transitive dependency.



Problems with Transitive Dependencies



Insertion Anomalies – If we need something to be entered in order to find out something else then if it is not entered we will never know the outcome



Deletion anomalies-If you create a table that- shows that if you delete a boy and the only way to know the father is with the boy then you lose in on the father.



Modification Anomalies-If you make modifications than it could cause problems if you modify one thing and you will have to modify other things.











PhysID	PatID	PatName	PatAddr	Specialty
5	123456	David	999 Street	Cancer



• We have a transitive dependency because the specialty is transitively dependent on the PhysID and we assume there is only one specialty per Physician.  The only way we can know that Cancer is the specialty is for a patient to require treatment for Cancer.





WHAT DO WE DO????????????aaaaaaaaaaaahhhh!!!!!!!!!!!!



• It is very easy all we need to do is remove the dependency.  Instead of having everything on one table you create another table and just use a foreign key to refer to it.  That will eliminate the Transitive Dependency.  We do the same as when we put PhysID in the Patient table.  This eliminates the transitive dependency because now you can tell what specialty has without needing the patient to require treatment.



Example:

Physician Table

PhysID

PhysName

PhysAddr





Patient Table

PatID

PatName

PatAddr

PhysID







MORE????????

NO! NO! NO!!!!!!













One more to go



















Of course assuming



• 3NF is done
• And the non-key attributes are full functional dependent on the Primary key.



What if you have an attribute and you must modify it?  Won’t this modification cause you to need to modify it some where else.



Example:

Student ID	Major	GPA	Advisor
123	CIS	3.6	David
456	MGMT	3	BOB
789	MKT	2.5	David
444	ACCT	2	Larry















If David was to retire we would have to make two changes and if the table were larger we have to make many changes.  Wouldn’t it be better to a second table?Hmmmm Why not?

Yes, if we create a second table then a modification only has to be done once.









Student

Student ID	Major	GPA	Advisor
123	CIS	3.6	Have an Advisor ID so you can just make the change in the advisor table and it will change the other tables that refer to it.     999
456	MGMT	3	888
789	MKT	2.5	999
444	ACCT	2	777





Advisor

AdvID	Name
999	David
888	BOB
777	Larry







 YES!!!!!!!!!!



















Short Answer Questions





What is Normalization?



Answer:

“Normalization is the formal process of determining which attributes should be grouped together in a relation”







Briefly explain (1NF)?



Answer:

The goal is to not have repeating columns.   You eliminate these columns by making sure all attributes are defined for the primary key.  Also, the attributes must be functionally dependent on the primary key.





Briefly explain (2NF)?



Answer:

The goal is to eliminate all the non-key attributes because it causes problems.  The best way to do that is to decompose a table into two and have the non-key information on the other table.  Also, if you decompose the tables you make sure that all attributes are fully functionally dependent on the primary key.  You want them dependent on a single primary key.





Briefly explain (3NF)?



Answer:

The goal is to eliminate transitive relationships because they cause anomalies. Also

“Transitive Relationship is a functional dependency between two (or more) non-key attributes.”  By decomposing the tables you will eliminate them because you will eliminate the non-key attributes and move them to the tables that they need to go to.







What is (BNF) and what happens in (BNF)?



Answer:

The goal is to eliminate a modification anomaly.  If you have a table and you need to modify it then you will have to modify every occurrence of it.  If you decompose the table and link it to another all you need to do is modify in one table and it will modify everywhere else.



What is Functional Dependency?



Answer:

When attributes can be determined by another attribute it means they are functionally dependent.  In the example you see that the attributes are not no longer functionally dependent on PhysID but on PatID as well.  This problem creates duplication and possibly errors.







Name three problems with transitive dependencies?



Answer:

Insertion Anomalies – If we need something to be entered in order to find out something else then if it is not entered we will never know the outcome



Deletion anomalies-If you create a table that- shows that if you delete a boy and the only way to know the father is with the boy then you lose in on the father.



Modification Anomalies-If you make modifications than it could cause problems if you modify one thing and you will have to modify other things.





Multiple Choice



1)My goal it to eliminate all transitive dependencies which form am I going into?



A.(2NF)                       B.(3NF)

C.(4NF)                       D.Insertion Anomaly



Answer: B



2)If we need something to be entered in order to find out something else then if it is not entered we will never know the outcome what kind of anomaly is this?



A.Insertion                   B.Deletion

C.Modification D.Separation



Answer: A



3)If we say a foreign key cannot exist unless it is a primary key in another table and/relation.  The foreign key can also be null. What is this an example of?



A.Relational Integrity                B.Entity Integrity

C.Functional Dependency         D.Insertion anomaly



Answer:  A

4) If you make modifications than it could cause problems if you modify one thing and you will have to modify other things what kind of anomaly is this?



A.Insertion                   B.Deletion

C.Modification D.Separation



Answer:  C

5) If you create a table that- shows that if you delete a boy and the only way to know the father is with the boy then you lose in on the father what kind of anomaly is this?

A.Insertion                   B.Deletion

C.Modification D.Separation



Answer:  B



References:





1. http://databases.about.com/library/weekly/aa080501a.htm
2. http://itmanagement.webopedia.com/TERM/N/normalization.html
3. http://troubleshooters.com/littstip/Itnorm.html
4. Kirs, Peeter Database Design, Lecture slides.
